Multi-product calibrator for new and inexperienced workers

Fluke introduces the Fluke 5560A High-Performance Multi-Product Calibrator, which provides the broadest electrical workload coverage and highest accuracy.

The 5560A sits neatly in Fluke’s product range under the high-accuracy, multi-function 5730A calibrator designed for calibrating 8.5-digit resolution DMMs. The 5560A is a solution for calibrating up to 6.5-digit DMMs.

With demand for calibration growing every year, the Fluke 5560A defines a new class of multi-product calibrator by catering for new and inexperienced workers joining the calibration business without much training. Key features of the Fluke 5560A include a large 7-inch display with intuitive touchscreen for ease of use, Visual Connection Management terminals and an optional accessory for efficient digital multimeter (DMM) calibration with minimal or no lead changes. The rugged and portable calibrator can also be automated using MET/CAL Calibration Management Software.

Among the key benefits to users of the 5560A are minimal training requirements and reduced maintenance as well as the ability to calibrate a wider range of equipment using a single calibrator. These all contribute to significant reductions in cost of ownership for calibration laboratories. The 5560A is also protected against expensive damage caused by incoming voltages or overload conditions.

Fluke Calibration has also launched the 5550A Performance Multi-Product Calibrator which enhances the highly popular multi-product 5522A to provide a better match for a customer’s existing DMM workloads. The 5550A greatly improves the accuracy delivered by the 5522A 5.5-digit DMMs as well as offering greater functionality. Featuring an intuitive graphical interface, the 5550A can calibrate the most popular handheld DMMs with increased test uncertainty ratios (TURs) and clamp meters to 1500 A with continuous current output (30 A).

Flexible calibration on-site and in the field

The 5540A Multi-Product Calibrator is another new addition to enhance Fluke Calibration’s improved range. It extends the capabilities of the 5502A with better performance levels, making it an ideal solution for on-site or mobile calibration of the most demanding field instrumentation workloads. The 5540A is suitable for calibrating handheld 4.5-digit resolution DMMs with increased TURs and clamp meters to 1500 A with continuous current output. Improvements in comparison to the 5502A include an increase from 20 A to 30 A of continuous current output and cutting waiting times during heavy usage. A wider range of thermocouple types and a new easy-connect thermocouple connector widen the temperature workload coverage of the calibrator. The 5540A can be fully calibrated with a Fluke 8588A 8.5-digit Reference Multimeter plus one shunt for the highest current range.
